Data: • HVI certified CFM: 600 on high (with
8”round duct); 580 on high (3-1/4 x 10”
duct)
• CRT (Code-Ready Technology) allows
you to change CFM to 400 or 300 CFM
at installation, allowing the ventilator
to conform to make-up air code
requirements, where applicable.
• Stainless-steel finish
• Sones on high: 9.5; Sones on low: 3.3
• Bright LED lights, 3-level (2 modules):
- Wattage: 3W -
CCT (color temp.): 3,000K
- Lumens: > 300
- Rated Life: > 25,000 hrs.
• Max CFM: 650 (pre-installation)
• 4-speed electronic soft touch control
buttons
• Baffle-style quick-release filter (dishwasher
safe)
• Auto-sensing feature (when activated)
sets CFM to correct level for what is being
prepared on cooktop.
• Wi-Fi enabled feature allows for voice
control using Alexa/Google, if desired.
• Heat sentry automatically turns unit on
when excessive heat is detected.
• Unit has master on-off switch (to meet
future standards)
• Ducting: 8” round, 6” round or 3-1/4” x 10”
• Power requirements: 120 VAC, 60 Hz -
4.0 AMPS
